SPECIALIZED DRONE PROPULSION SOLUTIONS FOR INDUSTRY, AGRICULTURE AND ENTHUSIASTS

M6 CODE08 260KV

M6 INDUSTRY PRO EDITION UAV motor is designed to achieve waterproof and dustproof IP35 degree of protection.  Design compatibility of mounting holes for propeller and setup installation. High performance and low power consumption at high voltage applications.

M6 INDUSTRY AND AGRICULTURE

M6 CODE08 260KV IPE

INDUSTRY PROFESSIONAL EDITION
  • Water and dust proof IP35 degree of protection
  • Internal fan for active heat dissipation
  • Ultra durable bearings
  • Propeller installation adapters
  • Motor mounting holes standarization
  • Repairable
  • Maximized performance
  • Low power consumption
  • Designed for 8S-12S voltage

M6 CODE08 260KV IPE

MSRP $109.00

TAX EXCLUDED

PERFORMANCE & BENCHMARKS

For interactive performance charts, please visit application store for iOS or Android mobile devices and download MAD Configurator for free.

SPECIFICATIONS

M6 CODE08
Configuration24N22P
RPM/V260KV
Stator Size64 x 08 mm
Motor Dimensions72 x 29.5 mm
Shaft Diameter6 mm
Continuous Power (60 mins)TBA
Maximum Power (60 secs)TBA
Maximum Current (60 secs)TBA
Idle Current at 16VTBA
Internal Resistance26 mΩ
Motor Weight270 g
Product Boxed Weight350 g
IPE
Heat DissipationCentrifugal Fan
Rotor BalancedYes
Heavy Duty DesignYes
Degree of ProtectionIP35
Maximum ThrustTBA
Efficiency at 750 g ThrustTBA
Propeller Mounting Holes4 x M3 Ø12 / Ø18 / Ø22 mm
Motor Mounting Holes4 x M3 Ø30 / Ø30 mm
WireWinding Extended 150 mm
Propeller AdapterNo
Additional Accessories3x Bullet Connector Set
3x Heat Shrink Tubes
2x M3 10mm
1x Prop Cover
1x MAD Stickers
2x Black Foam with Hole - Stand for Cup

RECOMMENDATIONS

Propeller size20" - 24"8S
Propeller size16"-18"12S
Takeoff WeightTBA8S
Takeoff WeightTBA12S

DOWNLOADS

MAD motors images in ZIP file
Free to use for distributors only

MAD motors brochure PDF file
